Marchesini PS300 semi-auto case packer – fully enclosed version

Marchesini Pack Service PS300 semi-automatic case packer for small to medium output production requirements; suitable for: Contract Packing, Pharmaceutical, Cosmetics, Nutraceutical, Medical Devices and other industries.

Fully enclosed and guarded structure – for extra safety for operators.

Originates from prominent pharmaceutical manufacturing in Europe.

Machine size: Length: 2600mm (including infeed conveyor) x Width: 1300mm (incl. outfeed roller conveyor); Height: 1900mm W/T; 650kg

The pre-formed cases must be placed directly on the loading area. Cartons are fed by conveyor from the machine in front of PS300 into its stacking unit, where they are collated upwards, as it is programmed through the Operator Interface Panel.

The case is then automatically fed and discharged on a free running conveyor.

Technical Info:

Case Sizes:

- Length: 200mm to 600mm

- Width: 125mm to 400mm

- Height: 65mm to 300mm

Individual Product Box Sizes:

- Length: 25mm to 580mm

- Width: 10mm to 120mm

- Height: 65mm to 300mm

- Wide range of cases and products working sizes

- Cases feeding area is entirely safe, free from any mechanical movement

- Torque overloading control on every motor.

- Fast and easy change over, with digital indicators and quick fixing of mobile change parts

- Electric supply: 380V, 50Hz, 3 kW
